The new family of `text_*()` functions in {gt} 0.9.0

What is a text transformation in gt?

Before we get down to what’s new, we probably ought to understand what text transformation means in gt. Let’s focus on the body cells of a table, which might otherwise be known as data cells. When they enter into gt via the gt() function, they are unformatted. The package offers a variety of fmt_*() functions for formatting these values, whether they are numeric values, logical values, text, etc. The formatting functions constitute phase one of the pipeline.

Next, in phase two, we have the substitution functions and they are of the form sub_*(). These are useful functions for dealing with common replacement tasks, and they utilize the underlying data behind a formatted value (e.g., the value 1 might be formatted to become "one" but the sub_*() functions still see that as the value 1). You can think of these as secondary formatting functions, and they may handle specialized data presentation cases like replacing very large or very small values with specific text.

Alright, this brings us to phase three (the final phase), and it’s where the text transformation functions finally come in. The text_*() functions handle the cell data that are flattened into strings, and, importantly, they don’t have access to the underlying data. Say a 1 value is formatted as "one", then it undergoes substitution to become "less than five"; the text_*() functions will take that input as "less than five". All of the text transformation functions operate on a vector of these formatted strings and return an equal-length vector of transformed strings. Even if there was no formatting or substitution done, gt will still automatically cast all of the body cell values as strings before entering this third phase.

To recap:

• Phase One: formatting with fmt_*() (input is original data values)
• Phase Two: substitution with sub_*() (selected values are replaced; original data values are still accessed)
• Phase Three: transformation with text_*() (input is string-based, original data values are disregarded)

We can think of text transformation as post-processing because it comes at the end of this three-phrase pipeline (where the initial values no longer matter) and we are making arbitrary changes to the strings that will be presented. Alright, let’s now look at all those new text_*() functions!

The new text_replace() function

The text_replace() function provides a specialized interface for replacing text fragments in a manner similar to how gsub() works. You specify which cells are to be transformed with the locations argument (this takes in one or more cells_*() function calls). Once that is done, the remaining two values to supply are the regex pattern (pattern) and the replacement for all matched text (replacement).

A simple example is in order. We’re making a gt table from the sza dataset, and the formatting of the time values in the tst column to the "fr-CA" locale is close to what we want, but not quite. Luckily, we have text_replace() to fix up those time values to a more desirable form.

sza |>
  dplyr::filter(latitude == 40) |>
  dplyr::select(-latitude) |>
  dplyr::mutate(month = as.integer(month)) |>
  tidyr::pivot_wider(names_from = month, values_from = sza) |>
  dplyr::mutate(tst = paste0(substr(tst, 1, 2), ":", substr(tst, 3, 4))) |>
  gt(locale = "fr-CA") |>
  cols_width(
    tst ~ px(75),
    everything() ~ px(50)
  ) |>
  data_color(
    columns = where(~is.numeric(.x)),
    palette = c("yellow", "darkblue"),
    domain = c(0, 90),
    na_color = "darkblue" |> adjust_luminance(steps = -1)
  ) |>
  cols_label(
    tst ~ "TSV"
  ) |>
  sub_missing(missing_text = "") |>
  fmt_time(columns = tst, time_style = "Hm") |>
  text_replace(
    pattern = "(^0| )",
    replacement = "",
    locations = cells_body(columns = tst)
  )

We needed to eliminate leading zero values and remove the internal spaces in the times. The pattern "(^0| )" targets those characters and using replacement = "" eliminates them! Now, a value like "08 h 30" becomes "8h30" and this presents much better.

The new text_case_when() function

The text_case_when() function provides a useful interface for a case-by-case approach to replacing entire table cells. To use it you supply a sequence of two-sided formulas of the general form: ⁠<logical_stmt> ~ <new_text>⁠. On the left hand side there should be a predicate statement that evaluates to a logical vector of length one (i.e., either TRUE or FALSE). To refer to the values undergoing transformation, you need to use the x variable.

Example time! We’ll use the metro dataset this time to create a gt table. For the connect_rer column (targeted in .locations), we perform counts of pattern matches with stringr::str_count() within text_case_when() and determine which cells have 1, 2, or 3 matched patterns. For each of these cases, we will provide descriptive replacement text. Here, we also use a .default value of "" to replace the non-matched cases with an empty string.

metro |>
  dplyr::arrange(desc(passengers)) |>
  dplyr::select(name, lines, connect_rer) |>
  dplyr::slice_head(n = 10) |>
  gt() |>
  text_case_when(
    stringr::str_count(x, pattern = "[ABCDE]") == 1 ~ "One connection.",
    stringr::str_count(x, pattern = "[ABCDE]") == 2 ~ "Two connections.",
    stringr::str_count(x, pattern = "[ABCDE]") == 3 ~ "Three connections.",
    .default = "",
    .locations = cells_body(columns = connect_rer)
  ) |>
  cols_label(
    name = "Station",
    lines = "Lines Serviced",
    connect_rer = "RER Connections"
  )

We get the appropriate replacement in the connect_rer column for each case that was defined in text_case_when(). Anything that was not matched now appears as an empty body cell.

The new text_case_match() function

The text_case_match() function lets us replace table cells with an interface that behaves much like a switch statement. You supply a sequence of two-sided formulas of the general form: ⁠<vector_old_text> ~ <new_text>⁠. In the left hand side (LHS) there should be a character vector containing strings to match on. The right hand side (RHS) should contain a single string (or something coercible to a length one character vector). By default, text_case_match() will try to match on entire strings and replace those strings.

Let’s use towny to create a fresh new gt table. We will transform the text in the csd_type column using two-sided formulas supplied to text_case_match(). We can replace matches on the LHS with Font Awesome icons furnished by the fontawesome R package:

towny |>
  dplyr::select(name, csd_type, population_2021) |>
  dplyr::filter(csd_type %in% c("city", "town")) |>
  dplyr::group_by(csd_type) |>
  dplyr::arrange(desc(population_2021)) |>
  dplyr::slice_head(n = 5) |>
  dplyr::ungroup() |>
  gt() |>
  fmt_integer() |>
  cols_label(
    name = "City/Town",
    csd_type = "",
    population_2021 = "Population"
  ) |>
  text_case_match(
    "city" ~ fontawesome::fa("city"),
    "town" ~ fontawesome::fa("house-chimney")
  )

A "city" gets one icon while a "town" gets another. What fun!

By default, the LHS is matched against the entire string in any given cell. However, fragments of text can be replaced when using the .replace = "partial" option. Let’s demonstrate how this option works through a gt table made with the pizzaplace dataset. In the size column, we can replace the "S", "M", and "L" letters with the "small", "medium", and "large" equivalent. We can also replace any instances of "X" with "extra ":

pizzaplace |>
  dplyr::mutate(size = factor(
    size, levels = c("S", "M", "L", "XL", "XXL")
  )) |>
  dplyr::group_by(size) |>
  dplyr::summarize(sales = sum(price)) |>
  dplyr::ungroup() |>
  gt() |>
  fmt_currency() |>
  text_case_match(
    "S" ~ "small",
    "M" ~ "medium",
    "L" ~ "large",
    "X" ~ "extra ",
    .replace = "partial"
  )

It may not be apparent, but the replacements will be in sequence order and changes are made immediately (i.e., the next case will work on the result of the prior case). Here’s an example of that using the row column of the exibble dataset:

exibble |>
  dplyr::select(number = row) |>
  dplyr::slice_head(n = 5) |>
  gt() |>
  text_case_match(
    "row_" ~ "",
    "1" ~ vec_fmt_percent(100, scale_values = FALSE),
    as.character(2:3) ~ vec_fmt_number(2),
    "4" ~ vec_fmt_index(4),
    "5" ~ fontawesome::fa("5"),
    .replace = "partial"
  )

Once the leading "row_" text was removed (e.g., "row_1" became "1"), we could write cases based solely on the remaining string-based numbers.

The not-so-new text_transform() function

The text_transform() function is not new, it’s actually been part of the package since the beginning. Despite this, it is worth re-examining this function, which provides the most general interface of all the ⁠text_*()⁠ functions available in this family. With text_transform(), you target the cells to undergo modification in the locations argument while also supplying a function to the fn argument. With that provided function, text_transform() will take the input x vector and return a transformed x of the same length. Using the construction function(x) { .. } for the function given to fn is recommended.

Let’s look at an example that uses the sp500 dataset. We will transform the text in the date column using a function supplied to the fn argument. Note that the x in the ⁠fn = function (x)⁠ part consists entirely of ISO 8601 date strings from the date column (these are acceptable as input to the vec_fmt_date() and vec_fmt_datetime() functions).

sp500 |>
  dplyr::slice_head(n = 10) |>
  dplyr::select(date, open, close) |>
  dplyr::arrange(-dplyr::row_number()) |>
  gt() |>
  fmt_currency() |>
  text_transform(
    fn = function(x) {
      paste0(
        "<strong>",
        vec_fmt_date(x, date_style = "m_day_year"),
        "</strong>",
        "&mdash;W",
        vec_fmt_datetime(x, format = "w")
      )
    },
    locations = cells_body(columns = date)
  ) |>
  cols_label(
    date = "Date and Week",
    open = "Opening Price",
    close = "Closing Price"
  )

In the function defined for the fn argument, we got to use x twice: first to generate a date in a month-day-year format, and secondly to add a week number. The result is a combined date-and-week string that provides additional clarity to the presentation.

Now let’s use the gtcars dataset for our next text_transform() example. First, the numeric values in the n column will be formatted as spelled-out numbers with fmt_spelled_num(). The output values will indeed be spelled out but exclusively with lowercase letters. We actually want these words to begin with a capital letter and end with a period. Through the fn argument in text_transform(), we’ll provide a custom function that uses toTitleCase() to operate on x (the numbers-as-text strings) within a paste0() so that a period can be placed after that transformed text.

gtcars |>
  dplyr::select(mfr, ctry_origin) |>
  dplyr::filter(ctry_origin %in% c("Germany", "Italy", "Japan")) |>
  dplyr::group_by(mfr, ctry_origin) |>
  dplyr::count() |>
  dplyr::ungroup() |>
  dplyr::arrange(ctry_origin, desc(n)) |>
  gt(rowname_col = "mfr", groupname_col = "ctry_origin") |>
  cols_label(n = "No. of Entries") |>
  tab_stub_indent(rows = everything(), indent = 2) |>
  cols_align(align = "center", columns = n) |>
  fmt_spelled_num() |>
  text_transform(
    fn = function(x) {
      paste0(tools::toTitleCase(x), ".")
    },
    locations = cells_body(columns = n)
  )

There are unlimited ways you can transform your text with text_transform(). With a little creativity, anything’s possible!

Conclusion

We strive to improve the gt package so that it can work better for you. New functions are always a good thing and we hope you can make good use of these additions! If you encounter problems you can always file an issue on GitHub. A good place to ask questions on GitHub is in the gt Discussions page.

If you can believe it, the gt package has its own Twitter account. It’s at @gt_package, so follow us there for news and more. We also recommend joining the gt_package Discord server. It is active, lots of fun, and you ought to drop by!
