New formatting functions in {gt} 0.9.0

Formatting URLs with fmt_url()

Some tables feature URLs and, previously, it wasn’t easy to create links from those. For HTML output tables, you either had to create Markdown links and apply the fmt_markdown() function, or use text_transform() and construct tags. Now, with gt 0.9.0, we can use the new fmt_url() function. Here’s an example that uses the new towny dataset (which contains URLs in its website column). What we see and get are URLs as navigable links.

library(gt)
library(dplyr)

towny |>
  dplyr::slice(65:70) |>
  dplyr::arrange(desc(population_2021)) |>
  dplyr::select(name, website) |>
  gt() |>
  fmt_url(columns = website)

By default, the links are underlined, and the color will be chosen for you by default (it’s dark cyan here). You can choose a different color with the color argument.

Let’s try something else now. It’s possible to set a static text label for the link with the label argument (and we’ll use the word "site" for this). The link underline is removable with show_underline = FALSE, and we’re going to use that option. With these changes to the defaults, it now seems sensible to merge the link to the name column and enclose that link text in parentheses (the trusty cols_merge() function can handle all that).

towny |>
  dplyr::filter(csd_type == "city") |>
  dplyr::arrange(desc(population_2021)) |>
  dplyr::select(name, website, population_2021) |>
  dplyr::slice_head(n = 10) |>
  gt() |>
  tab_header(
    title = md("The 10 Largest Municipalities in `towny`"),
    subtitle = "Population values taken from the 2021 census."
  ) |>
  fmt_integer() |>
  cols_label(
    name = "Name",
    population_2021 = "Population"
  ) |>
  fmt_url(
    columns = website,
    label = "site",
    show_underline = FALSE
  ) |>
  cols_merge(
    columns = c(name, website),
    pattern = "{1} ({2})"
  )

In that example we used a few other functions (tab_header(), fmt_integer(), and cols_label()) to make the table present a bit better. A title, formatted numbers, and nice column labels are always good to have!

The fmt_url() function allows for the styling of links as ‘buttons’. This is as easy as setting as_button = TRUE. Doing that allows us to set a button_fill color. This color can automatically selected by gt (this is the default with button_fill = "auto") but here we’re going to instead opt for "steelblue". The label argument is flexible in that it also accepts a function. With that we choose to construct the label text from the URLs by eliminating any leading "https://" and "www." parts via gsub().

towny |>
  dplyr::filter(csd_type == "city") |>
  dplyr::arrange(desc(population_2021)) |>
  dplyr::select(name, website, population_2021) |>
  dplyr::slice_head(n = 10) |>
  dplyr::mutate(ranking = dplyr::row_number()) |>
  gt(rowname_col = "ranking") |>
  tab_header(
    title = md("The 10 Biggest Municipalities in `towny`"),
    subtitle = "The population values were taken from the 2021 census."
  ) |>
  fmt_integer() |>
  cols_move_to_end(columns = website) |>
  cols_align(align = "center", columns = website) |>
  cols_width(
    ranking ~ px(40),
    website ~ px(200)
  ) |>
  tab_options(column_labels.hidden = TRUE) |>
  tab_style(
    style = cell_text(weight = "bold"),
    locations = cells_stub()
  ) |>
  opt_vertical_padding(scale = 0.75) |>
    fmt_url(
    columns = website,
    label = function(x) gsub("https://|www.", "", x),
    as_button = TRUE,
    button_fill = "steelblue",
    button_width = px(150)
  )

Missing values are a fact of life when doing things in R, but thankfully the fmt_url() function will preserve input NA values, allowing you to handle them with sub_missing(). Here’s an example of that:

towny |>
  dplyr::arrange(population_2021) |>
  dplyr::select(name, website, population_2021) |>
  dplyr::slice_head(n = 10) |>
  gt() |>
  tab_header(
    title = md("The 10 Smallest Municipalities in `towny`"),
    subtitle = "Population values taken from the 2021 census."
  ) |>
  cols_label(
    name = "Name",
    website = "Site",
    population_2021 = "Population"
  ) |>
  fmt_integer() |>
  fmt_url(
    columns = website,
    color = "forestgreen"
  ) |>
  sub_missing(
    columns = website,
    missing_text = "No website available."
  )

Some places just don’t have a website (can’t really blame them) and we can provide a simple explanation for the lack of one by using sub_missing() on the column formatted with fmt_url().

Many tables have URLs (we’ve all seen them), and having them be links shouldn’t be an arduous process. The fmt_url() function makes handling this type of cell data easier, and we can’t wait to see all the tables that use it!

Transforming numbers with fmt_index() and fmt_spelled_num()

The two new formatting functions fmt_index() and fmt_spelled_num() take in numbers (whole numbers, that is), and the former returns letters while the latter gives us numbers that are fully spelled out (with letters). These are great little formatting functions to have when you need to have ordering or classifying text that originate from numbers. Also, these functions have a lot of internationalization built in! Both have a locale argument for controlling which index values and which spelled out numbers are returned.

The fmt_index() function can give us index values, which are usually based on letters (depending on the locale chosen). For example, the value 4 will be rendered as "D" if the locale is an English-language one. The characters chosen for indexing here are based on character sets intended for ordering (and these often leave out characters with diacritical marks).

Let’s get to an example to understand one use case. We’ll use that towny dataset and do some serious dplyring to it. After introducing the transformed/summarized data to gt(), the fmt_index() function is used to transform the incrementing integer values into capitalized letters (in the ranking column). That formatted column of "A" to "E" values is merged with the census_div column (through cols_merge()) to create an indexed listing of census subdivisions, here ordered by increasing total municipal population.

towny |>
  dplyr::select(name, csd_type, census_div, population_2021) |>
  dplyr::group_by(census_div) |>
  dplyr::summarize(
    population = sum(population_2021),
    .groups = "drop_last"
  ) |>
  dplyr::arrange(population) |>
  dplyr::slice_head(n = 5) |>
  dplyr::mutate(ranking = dplyr::row_number()) |>
  dplyr::select(ranking, dplyr::everything()) |>
  gt() |>
  tab_header(title = md("The smallest  \ncensus subdivisions")) |>
  fmt_integer() |>
  cols_align(align = "left", columns = ranking) |>
  tab_options(table.width = px(325)) |>
  fmt_index(columns = ranking, pattern = "{x}.") |>
  cols_merge(columns = c(ranking, census_div)) |>
  cols_label(
    ranking = md("Census  \nSubdivision"),
    population = md("Population  \nin 2021")
  )

Let’s move on to the fmt_spelled_num() function. We added that so that numeric values could be transformed to spelled out numbers. Any values from 0 to 100 can be spelled out according to a given locale value. For example, the value 26 will be rendered as "twenty-six" if the locale is an English-language one (or, not provided at all). We mentioned that these number-based formatting functions have i18n powers and it’s true. Using a Finnish locale (i.e., "fi") gives us the number 26 spelled out as "kaksikymmentäkuusi".

Using the gtcars dataset, we look at how fmt_spelled_num() might be useful. After the requisite summarizing and arranging of rows, the fmt_spelled_num() function can be used to transform integer values into spelled-out numbering (in the n column). That formatted column of numbers-as-words is given cell background colors via data_color().

gtcars |>
  dplyr::select(mfr, ctry_origin) |>
  dplyr::group_by(mfr, ctry_origin) |>
  dplyr::count() |>
  dplyr::ungroup() |>
  dplyr::arrange(ctry_origin) |>
  gt(rowname_col = "mfr", groupname_col = "ctry_origin") |>
  cols_label(n = "No. of Entries") |>
  tab_stub_indent(rows = everything(), indent = 2) |>
  opt_all_caps() |>
  opt_vertical_padding(scale = 0.5) |>
  cols_align(align = "center", columns = n) |>
  fmt_spelled_num() |>
  data_color(
    columns = n,
    method = "numeric",
    palette = "viridis",
    alpha = 0.8
  )

Why does data_color() work? It might be confusing but the underlying data in the n column are still numeric (even though they’ve been formatted to text-based values).

Anyway, both fmt_index() and fmt_spelled_num() have vector-formatting analogue functions: vec_fmt_index() and vec_fmt_spelled_num(). This is useful when you want to apply this type of formatting on numeric vectors. You never really know when you’ll need any of these four new functions, but they will be ready when you are.

Easily using images in data cells with fmt_image()

To easily insert graphics into body cells, we can use the new fmt_image() function. This allows for one or more images to be placed in the targeted cells. For this to work optimally, the cells undergoing formatting have to contain some reference to an image file. This can be in one of three basic forms:

1. complete http/https or local paths to the files,
2. the file names, where a common path can be provided via path, or
3. a fragment of the file name, where the file_pattern helps to compose the entire file name and path provides the path information

This should be expressly used on columns that contain only references to image files (i.e., no image references as part of a larger block of text). A cool aspect of fmt_image() is that multiple images can be included per cell by separating image references by commas.

In our next example, we are going to use the new metro dataset to create a gt table full of images (though we’ll only include a few columns and rows from that table). The lines and connect_rer columns have comma-separated listings of numbers/letters (corresponding to Metro and RER lines served at each Metro station, respectively). We actually have a directory of SVG graphics for all of these lines in the package (the path for the image directory can be accessed via system.file("metro_svg", package = "gt")), and the filenames for those SVG graphics have some correspondence to the data in those two columns. The fmt_image() function can be used with these inputs since the path and file_pattern arguments allow us to compose complete and valid file locations.

metro |>
  dplyr::select(name, caption, lines, connect_rer) |>
  dplyr::slice_head(n = 10) |>
  gt() |>
  cols_merge(
    columns = c(name, caption),
    pattern = "{1}<< ({2})>>"
  ) |>
  text_replace(
    locations = cells_body(columns = name),
    pattern = "\\((.*?)\\)",
    replacement = "<br>(<em>\\1</em>)"
  ) |>
  sub_missing(columns = connect_rer, missing_text = "") |>
  cols_label(
    name = "Station",
    lines = "Lines",
    connect_rer = "RER"
  ) |>
  cols_align(align = "left") |>
  tab_style(
    style = cell_borders(
      sides = c("left", "right"),
      weight = px(1),
      color = "gray85"
    ),
    locations = cells_body(columns = lines)
  ) |>
  opt_stylize(style = 6, color = "blue") |>
  opt_all_caps() |>
  opt_horizontal_padding(scale = 1.75) |>
  fmt_image(
    columns = lines,
    path = system.file("metro_svg", package = "gt"),
    file_pattern = "metro_{x}.svg"
  ) |>
  fmt_image(
    columns = connect_rer,
    path = system.file("metro_svg", package = "gt"),
    file_pattern = "rer_{x}.svg"
  )

Station	Lines	RER
Argentine
Bastille
Bérault
Champs-Élysées—Clemenceau (Grand Palais)
Charles de Gaulle—Étoile
Château de Vincennes
Châtelet
Concorde
Esplanade de La Défense
Franklin D. Roosevelt

We can see sequences of images in the table cells, and they’re taken from the referenced graphics files on disk. The string "1,5,8" in row 2 of the table (in the lines column) corresponds to the SVG images "metro_1.svg", "metro_5.svg", and "metro_8.svg" in the directory referenced in the path argument.

Images used to be non-trivial to insert into gt tables. It is hoped that this eases the burden of making image-laden tables and that the functionality fits in well with most table-making workflows.

Country flags with fmt_flag() and easier formatting of ranges with fmt_bins()

While it is fairly straightforward to insert images into body cells (using fmt_image() is one way to it), there is often the need to incorporate specialized types of graphics within a table. One such group of graphics involves iconography representing different countries, and the fmt_flag() function helps with inserting a flag icon (or multiple) in body cells.

To make this work seamlessly, the input cells need to contain some reference to a country, and this is in the form of a 2-letter ISO 3166-1 country code (e.g., Mauritania has the "MR" country code). This function will parse the targeted body cells for those codes and insert the appropriate flag iconography. Multiple flag icons can be included per cell by having input data that separates country codes with commas (e.g., "DO,PA").

Let’s use the (now updated) countrypops dataset to create a gt table for our next example. We will only include a few columns and rows from that table. The country_code_2 column has 2-letter country codes in the format required for fmt_flag() and using that function transforms the codes in circular flag icons.

countrypops |>
  dplyr::filter(year == 2021) |>
  dplyr::filter(grepl("^S", country_name)) |>
  dplyr::arrange(country_name) |>
  dplyr::select(-country_code_3, -year) |>
  dplyr::slice_head(n = 10) |>
  gt() |>
  cols_move_to_start(columns = country_code_2) |>
  fmt_integer() |>
  cols_label(
    country_code_2 = "",
    country_name = "Country",
    population = "Population (2021)"
  ) |>
  fmt_flag(columns = country_code_2)

I personally enjoy these little flag icons so let’s look at another example. We’ll use countrypops again to make a table containing populations the Benelux countries ("BE", "NU", and "LU") at five-year intervals. This requires a little manipulation with dplyr and tidyr before introducing the table to gt but it’s worth it. As before, we’ll use fmt_flag() to generate flag icons in the country_code_2 column. Now here comes the interesting part: we can merge the flag icons into the stub column, and generate row labels that have a combination of icon and text. This mainly involves using a pattern where the flags are placed before the stub text ("{2} {1}").

countrypops |>
  dplyr::filter(country_code_2 %in% c("BE", "NU", "LU")) |>
  dplyr::filter(year %% 10 == 0) |>
  dplyr::select(country_name, country_code_2, year, population) |>
  tidyr::pivot_wider(names_from = year, values_from = population) |>
  dplyr::slice(1, 3, 2) |>
  gt(rowname_col = "country_name") |>
  tab_header(title = "Populations of the Benelux Countries") |>
  tab_spanner(columns = everything(), label = "Year") |>
  fmt_integer() |>
  fmt_flag(columns = country_code_2) |>
  cols_merge(
    columns = c(country_name, country_code_2),
    pattern = "{2} {1}"
  )

The fmt_flag() function works well even when there are multiple country codes within the same cell. It can operate on comma-separated codes without issue (e.g., "AD,BM,KY,DM" from the second row). When rendered to HTML, hovering over each of the flag icons results in tooltip text showing the name of the country.

countrypops |>
  dplyr::filter(year == 2021, population < 100000) |>
  dplyr::select(country_code_2, population) |>
  dplyr::mutate(population_class = case_when(
    population >= 80000 ~ "80K-100K",
    population >= 60000 ~ "60K-80K",
    population >= 40000 ~ "40K-60K",
    population >= 20000 ~ "20K-40K",
    population <  20000 ~ "0-20K"
  )) |>
  dplyr::group_by(population_class) |>
  dplyr::summarize(
    countries = paste0(country_code_2, collapse = ",")
  ) |>
  dplyr::arrange(desc(population_class)) |>
  gt() |>
  tab_header(title = "Countries with Small Populations") |>
  fmt_flag(columns = countries) |>
  cols_label(
    population_class = "Population Range",
    countries = "Countries"
  ) |>
  cols_width(population_class ~ px(150))

Now onto fmt_bins() and what it does. In the above example, we used the dplyr::mutate()/case_when() combination. However, it might be better in many cases to use a dplyr::mutate()/cut() approach. The cut() function has a lot of power behind it, and it produces intervals/bins that can look like this: "(0,10]", "(10,15]", "(15,20]", etc. That output doesn’t look great in a table, but fmt_bins() can format all of that to something that presents way better in a display table.

This is best seen in an example, and this one will tie together a few of the functions we explored earlier. The goal of this example is to present a table of countries that are binned by population. We don’t want any of the bins to be excessively large, so we’ll employ the cut() function in conjunction with the scales::breaks_log() function. With this, every country’s population (using year 2021 population estimates) will be assigned to a bin; these bins have the type of formatting that fmt_bins() can interpret. Here is the code and the resulting table:

countrypops |>
  dplyr::filter(year == 2021) |>
  dplyr::select(country_code_2, population) |>
  dplyr::mutate(population_class = cut(
    population,
    breaks = scales::breaks_log(n = 20)(population)
  )) |>
  dplyr::group_by(population_class) |>
  dplyr::summarize(
    count = dplyr::n(),
    countries = paste0(country_code_2, collapse = ",")
  ) |>
  dplyr::arrange(desc(population_class)) |>
  dplyr::mutate(tier = dplyr::row_number(), .before = population_class) |>
  gt() |>
  tab_header(title = "All Countries Grouped by Population Range") |>
  fmt_flag(columns = countries) |>
  fmt_spelled_num() |>
  fmt_index(columns = tier) |>
  cols_label(
    tier = "",
    population_class = "Population Range",
    count = "Count",
    countries = "Countries"
  ) |>
  cols_width(
    population_class ~ px(150),
    count ~ px(100)
  ) |>
  cols_align(align = "center", columns = c(tier, count)) |>
  opt_stylize(style = 6, color = "gray") |>
  opt_table_font(font = google_font("IBM Plex Sans")) |>
  opt_align_table_header(align = "left") |>
  data_color(columns = count, method = "numeric", palette = "viridis") |>
  fmt_bins(
    columns = population_class,
    fmt = ~ fmt_integer(., suffixing = TRUE)
  )

Using fmt_bins() can oftentimes be better than other methods for creating ranges. This is mainly because we can work directly with the interval output from cut(), and we can easily customize the presentation of those ranges. For instance, we have formatted the left and right values of the ranges with the fmt_integer() function (using formula syntax) in the example above. The default range separator, "--" (an en-dash), is nicely suited to expressing ranges, but we always have the option to modify that aspect of the presentation as well.

In closing

We enjoy putting in the work to improve the formatting functions in the package, and with gt version 0.9.0, we wanted to add some new members to the fmt_*() family. They can unlock new ways of expressing data in tabular form, and it will be fun to see all the new tables that use them!

We always want your feedback so always feel free to file an issue. Want to ask a question or discuss improvements before filing an issue? Try out the Discussions page in the gt repository for that. For news on gt and other table packages, follow the engaging @gt_package account on Twitter! We also have a new gt_package Discord server that’s both fun and educational.
